Vibro Paddy Classifier

SMALL STONE SEPARATOR

Rice Destoner is one of the secondary stage cleaning processes. Rice destoner remove small stones and impurities. This rice destoner works when the rice is elevated, leading the stones to move backwards towards the exit.

Orange gives you a new efficient packing solution with SAPM S75. Due to its small form factor, it becomes more convenient to fit directly under the hopper and does not occupy more room space. It is height is just 1 foot and 9 inches. So the user doesn't have to keep a separate hopper for the packing machine. It measures weight with the bag, hence the user can avoid the manual bag’s weight entry.

BULK RAW-PADDY CLEANING MACHINE

Double staged drum sieve mechanism designed to handle to clean Bulk quantity of paddy effortlessly even if contamination is very high. It can be equipped with Aspiration system to remove floating dust, preventing from dust spreading in and around campus.

WEIGHT BASED TONNAGE MACHINE

Flow meter is a highly versatile weighing system which measures Tonnage and Production for a Batch. This helps to find the efficiency of Milling process from Paddy pre cleaner I/P to Colour sorter O/P. FMFM 060240 used for bulk measurement in silo feeding and discharge. Hence we can measure the remaining quantity inside Silo.

ELEVATOR

Elevator is one of the most essential product in material handling and movement. Orange elevators are operated using an worm gear fixed motor and run with a calculated surface speed for better output performance.

WEIGHT BASED BLENDER

Orange Brings you a very accurate, user-friendly and high-speed blending machine for the industry. VieBland uses a state of the art technology in every component of the blending machine. VieBland uses an imported Load cell which needs fewer number of calibrations in its life span. The accepted level of weighing can be calibrated by the user itself. By understanding the requirement of users we have introduced many interesting features.

RICE SIZE GRADER

Rotary sifter is designed to separate broken rice depending upon their thickness. Rotary sifter comes with 11 optional screen sizes 1.8, 2.0, 2.5, 2.8, 3.0, 3.2, 3.5, 3.8, 4.0, 4.2, 4.5.

THICK AND THIN GRADER

Thickness Grader is designed specially to segregate/classify types of rice with respected to their thickness. Thickness grader requires very minimal amount of power for its best performance.

LARGE IMPURITIES REMOVER

Pre-Cleaner is one of the robust built machines which is used to separate the harvested paddy from lot unwanted products such as Hay, Big Stones, Mud balls, Unwanted Soil etc. It works by using traditional methods to get our output in an efficient and effective way.

Orange Brings you an accurate, user-friendly, high-speed packing machine for the industry. SAPM-D75NC uses state art technology in every component of the packing machine. SAPM-D75NC used the imported Load cell which needs less calibration in its life span. The acceptance level of weighing can be calibrated by the user itself. By understanding the requirement of users we have introduced many interesting features in SAPM-D75NC.

Orange has made packing machines to give the fastest efficient way of packing. SAPM-T75HC provides the best output tonnage. Using three individual weighing bin mechanisms the bag filling is done 75% faster than the usual single-head packing machine. SAPM-T75HC uses an advanced imported load cell that only requires a few calibrations in its entire lifetime. SAPM-T75HC is more efficient for customers who have large loads that had to be packed, stitched and loaded in a short duration of time.

HEAD RICE SEPARATOR

Length Grader is a specialized machine in segregating head rice from mixture of broken rice. Highly efficient segregation stars from High quality embossed sheet and calculated motor speed.

ABRASIVE STONE POLISHER

Whitener is otherwise known an abrasive polisher. This is a technique used to remove a layer of bran from rice by polishing using rough stones. The rice is gently passed through the abrasion chamber between specific silicon carbide stones and, by this process, the brown rice turns white. The removed bran is collected by the attached external suction blower.

WATER JET POLISHER

Silky polishes the outer surface of the rice with water through a rotating camshaft. Silky polisher comes with an inbuilt water atomizer system that sprays water evenly over rice and passes through a camshaft roller. Due to friction polishing and water mixture, the glazing rice resulted.

LARGE IMPURITIES AND SMALL STONES REMOVER

Paddy cleaner cum Destoner is a machine specifically designed to minimize power consumption and occupy mill space.

STONES SEPARATOR

A Paddy Destoner is a machine which removes stones, sand and clods from grains. Such as rice, paddy and beans. It works with the principle of vibrating an inclined sheet at a specific angle making the heavier particles move upward by giving a negative pressure from above. The suction mechanism removes dust and light weight unwanted particles.

PADDY HUSKER

Sheller is a machine with a compact structure with high efficiency by removing the husk layer which is present on the rice. It works with the concept of Rubber-Grain- Rubber frictional contact, successfully removing the husk without much damage to the grain.

HUSK REMOVER

Husk aspirators are widely used in modern rice mills because they help maintain grain quality, improve processing efficiency, and ensure proper separation of husk with minimal grain loss.

HUSK REMOVER

The husk separator is a machine which helps to separate brown rice, rice husk and dust. Aerodynamically designed structure helps to machine to work to its fullest performance.

PADDY AND RICE SEPARATOR

Paddy Separator Machine is used to separate the brown rice from the paddy that is not be husked, it words according to the difference of specific gravity, granularity and friction coefficient between paddy and brown rice, through the special separating tray to screen the mixture continuously, making it in stratification state.
